Application
The products are widely applicable to various power distribution room, the main plant, pump room, boiler room, corridor, bridge, bunker and other place for fixed lighting.
Characteristics
1. It adopts OSRAM brand light source, reliable performance, 20% or more brightness than similar products.
2. Lamps have cut power function, make the operation more secure.
3. Using advanced optical principle optimize transparent parts design, soft lighting, illumination uniformity, no glare, no ghosting, effectively prevent workers produce visual fatigue.
4. High strength aluminum alloy case, special sealed and surface coating processing, can be long-term used in hot and humid and corrosive harsh environments.
5. A variety of installation likes seat, ceiling and the ceiling, suitable to different needs of the job site for lighting.
6. According to needs of customers, can equip with protective cover for lamp.
Main specification
|
Input Voltage |
220VAC |
|
|
Rated frequency |
50Hz |
|
|
Light source |
Metal Halide Lamp |
|
|
Life time of light source (h) |
10,000 |
|
|
Space Height Ratio |
2.5 |
|
|
Screw Thread |
G3/4” |
|
|
Leading-cable diameter |
Φ8mm –Φ10mm |
|
|
Dimension |
270x230x300mm |
|
|
Net Weight |
6Kg |
|
Ordering reference
|
Model number |
Rated Wattage (W) |
Light Output (lm) |
Space height ratio |
Mounting height(m) |
|
ZY8600-J70 |
70 |
5,500 |
2 |
2~6m |
|
ZY8600-J100 |
100 |
9,000 |
||
|
ZY8600-J150 |
150 |
13,000 |
