Application
Suitable as place lighting for power plants, chemical device platform, substations, small and medium plants, channels and etc.
Characteristics
1. It adopts OSRAM brand light source, reliable performance.
2. Using anti-glare glass design, can reduce irritation to worker’ s eyes, avoid discomfort and fatigue.
3. Light fixtures is designed with shrapnel locking device, keep installation and maintenance more efficient and convenient
4. Multiple shock proof structure design and high-strength alloy casing, ensure that products can long-term work safely in roadbed, track, tunnel and other high-frequency vibration environment.
5. Special sealed and surface coating processing, can ensure the light fixtures Corrosion-resistant and non-rust in the humid, high temperature and other harsh environments.
6. A variety of installation types, like seat, ceiling and wall mounted.
7. Light angle can be adjusted in up and down (180 °) range according to the environment.
Main specification
|
Input Voltage |
220VAC 50Hz |
|
Rated frequency |
50Hz |
|
Life time of light source (h) |
10,000 |
|
Light source |
Metal Halide Lamp |
|
Leading-in cable diameter |
Φ6mm –Φ8mm |
|
Dimension |
340x293x208mm |
|
Net Weight |
4Kg |
Ordering reference
|
Model number |
Rated wattage (W) |
Light output (lm) |
Space height ratio |
Mounting height |
|
ZY8100-J70 |
70 |
5,500 |
4.5 |
2~8m |
|
ZY8100-J100 |
100 |
10,000 |
||
|
ZY8100-J150 |
150 |
10,000 |
