Application
1. It is an efficient lighting tool to be used at
the military, petrochemistry, oil field, customs inspection, police, patrol,
rescue relief, railway, fire fighting and any other night work tasks.
Characteristics
1. Certified by National authority. Flame proof type
of protection, designed according to explosion proof standard for safe use
potentially explosive atmosphere.
2. 3X3W CREE LED light source, 100,000 hrs service
life. Explosion proof torch light uses CREE LED light source, with 100,000hours
service life. The reflector adopts high-tech surface finishing technology, make
sure a high light reflectivity and no light shadow.
3. Its effective beam range is about 1,500meters.
4. Use of the latest high capacity lithium-iron
battery with long service life improves reliability and eliminates ‘ memory ‘
affect.
The strobe light can use as signal communication and
personal indicator to identify the position of the workers.
5. The body of the searchlight has treated with anodic
oxidation technology.
6. The flashlight is portable, also carried by the
shoulder strap.
7. The high strength aluminum alloy body can stand
harsh impact. explosion proof luminaire is well sealed to IP67.
8. Explosion proof searchlight has battery status
indication function, Operator can check the battery status at any time. The
recharging is controlled by chip with quick recharging, over charged
protection, short circuit protection and battery recharge level indication, etc.
Main specification
|
Specification |
Unit |
Values |
|
|
Rated voltage |
V |
22.2 |
|
|
Rated Power |
W |
9 |
|
|
Rated Capacity |
mAh |
2600 |
|
|
Light Output |
High |
lm |
975 |
|
Low |
465 |
||
|
Average Service |
h |
100，000 |
|
|
Continuous |
High |
h |
≥11 |
|
Low |
≥16 |
||
|
Frequency |
20 |
||
|
Recharge Time |
h |
≥8 |
|
|
Service Life Of |
Recycled |
≈1000 |
|
|
Dimension |
mm |
φ67* 140 |
|
|
Net weight |
Kg |
0.9 |
|
