Application
Ideal to be used in the environment of flammable gas and steam environment, such as Petrochemical Plant Chemical Plant Coal Washery, Pharmaceutical Factory, etc.
Characteristics
1. Equipped with international famous brand light source and electrical appliance, more stable performance and gives approximately 20% more light over the other manufacturer’s.
2. The average life span of the light source is more than 10000 hours. Therefore it is low maintenance .
3. Two Explosion-proof cavities structure. The wiring cavity is separated from the main flameproof cavity, enhancing safety.
4. Made of aluminium alloy, high strength. The spray coating treatment ensure the lamp waterproof, anti corrosion.
Main specification
|
Input Voltage |
220VAC 50Hz |
|
Ingress Protection |
IP65 |
|
Anti Corrosion Grade |
WF2 |
|
Insulation Grade |
I |
|
Thread |
G3/4” |
|
Leading-in cable diameter |
Φ9mm –Φ10mm |
|
Dimension |
Lamp 400x266x207mm |
|
Ballast 340x220x105mm |
|
|
Net Weight |
Lamp 5Kg |
|
Ballast 3.8Kg |
Ordering reference
|
Model No. |
Light Source |
Rated wattage (W) |
Light output (lm) |
Lamp Average Life (h) |
Temperature |
|
BC9100-J70 |
MH |
70 |
4,725 |
10,000 |
T6 |
|
BC9100-J100 |
MH |
100 |
6,750 |
10,000 |
T4 |
|
BC9100-J150 |
MH |
150 |
10,500 |
10,000 |
T4 |
Metal Halide Lamp: MH
